Air Curtain

Name: Air Curtain
Brand: Dolphy India Private Limited
Price: 13912.0 INR
Availability: InStock

Price 13912.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Air Curtain Specification

Power Mode
Electric

Diameter of wheel
120 mm

Frequency
50 Hz

Power Input
Single Phase AC

Place of Origin
India

Efficiency (%)
85%

Power Output
High Performance

Power Consumption
150 W

Air Volume
1050 m3/h

Air Velocity
18-20 m/s

Condition
NEW

Fan Speed
2 Speed

Material
Stainless Steel Body

Operating Voltage
220 V

Mounting
Wall Mounted

Voltage
220-240 V

Air Pressure
High

Noise Level
<50 dB

Dimension (L*W*H)
900 x 220 x 210 mm

Color
Silver

Weight
15 kg

Number of Motors
2

Insulation
Class B

Control Type
Remote / Switch

Application
Industrial, Commercial, Shop Entrance

Installation Service
Available

Length Options
3 ft, 4 ft, 5 ft Available

Protection Level
IP 20

Blower Material
Aluminium

Air Curtain Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About Air Curtain

Capitalise on exceptional value with our world-class Air Curtain, meticulously engineered for industrial, commercial, and shop entrances. Crafted from robust aluminium with a stainless steel body, it features unmatchable performance and high air velocity to ensure a clean, controlled environment. Enjoy unbeatable price without compromising on power-benefit from dual motors, advanced insulation (Class B), remote/switch control, and a high-efficiency blower system. With noise levels under 50 dB, a protection level of IP20, and installation service available, this Air Curtain delivers breathtaking efficiency with every use.

Versatile Air Curtain: Features & Applications

This Air Curtain stands out with remote or switch control, dual high-speed motors, and durable stainless steel body construction. Available in 3 ft, 4 ft, and 5 ft lengths, it suits a wide spectrum of entryways such as industrial workplaces, commercial spaces, and retail shops. Its high-pressure airflow ensures 75% insect and dust rejection, providing reliable protection for entrances up to 10 feet in height-making it ideal for both general and specific environmental control needs.

Packaging, Delivery & Certifications for Air Curtain

Our state-of-the-art logistics ensure secure packaging, safeguarding the Air Curtain against transit mishaps. Standard drop-off and freight options cater to clients across India, supporting seamless and timely deliveries. Expect swift dispatches, with delivery windows tailored based on your location and order size. Certifications verify compliance with top quality and safety standards, adding an extra level of trust for exporters, suppliers, or wholesalers seeking reliability and integrity in every shipment.

Model No.	DACN0004
Dimension (mm)	900 x 230 x 212
Max. Air Velocity At Nozzle	21 m/s
Noise Level DB	50 - 70 db
Body Material	Metal
Width Size	3 Feet
No. Of Blowers	3
No. Of Motors	2
HP	0.56
Voltage	220V/50Hz
No. Of Shafts	1 Single + 1 Double
Power Wattage	410W
Phase	Single
RPM (Max/Min)	2700 / 2100
Blower Material	ABS
CFM	825
Effective Height	7-10 Feet
% Insect / Dust Rejection	75%
Weight Kgs.	19

FAQ's of Air Curtain:

Q: How is the Air Curtain installed and what services are offered?

A: The Air Curtain is wall mounted and can be installed by our expert technicians. We offer complete installation service to ensure efficient setup and optimal operation at your facility.

Q: What are the primary benefits of using the Air Curtain at shop or facility entrances?

A: The Air Curtain provides high-efficiency dust and insect rejection (up to 75%), helps maintain desired indoor temperatures, and improves hygiene while reducing energy costs at entrance points.

Q: What is the recommended surface and height for Air Curtain application?

A: This product is ideal for entrances up to 7-10 feet in height and can be mounted on a variety of wall surfaces at industrial, commercial, or retail locations.

Q: Where is the Air Curtain manufactured and does it come with certifications?

A: The Air Curtain is manufactured in India and comes with certifications that meet international quality and safety standards, ensuring dependable performance and durability.

Q: How does the remote or switch control feature enhance usage?

A: The Air Curtain's remote or switch control allows convenient fan speed and power adjustments, enabling users to customise airflow and save energy as required.

Q: What is the delivery process and how is the Air Curtain packaged for shipping?

A: Products are securely packaged and dispatched via carefully managed logistics and freight channels, with delivery timelines communicated before drop-off. This guarantees safe arrival and product integrity.
